Surgical management of placenta percreta complicated by bladder invasion: a case report

Introduction

Placenta accreta spectrum (PAS) is characterized by abnormal placental invasion due to insufficient or complete loss of intervening decidua. Subtypes of PAS are classified by the depth of invasion: placenta creta invades through the endometrium and attaches to the myometrium, placenta increta invades into the myometrium, and placenta percreta invades through the uterine wall, often invading into nearby structures, most commonly the bladder (1-3). Urologic complications of PAS, including inadvertent cystotomy during hysterectomy, massive hemorrhage requiring therapeutic embolization and subsequent bladder necrosis, vaginal cuff necrosis, and vesicovaginal fistula formation, have all been described as individually rare in case reports (4-7), but are particularly notable in combination. To our knowledge, this is the first case report documenting the simultaneous combination of such complications (see timeline visualized in Figure 1). We present this case in accordance with the CARE reporting checklist (available at https://amj.amegroups.com/article/view/10.21037/amj-22-107/rc).

Figure 1 Case timeline. The timeline is indicated by gestational age of the patient’s baby and then by post-operative days after her first surgery. ED, emergency department; CS, caesarian section; ICU, intensive care unit; POD, post-operative day; OR, operating room; ER, emergency room; CT, computerized tomography.

Case presentation

A 30-year-old woman with a history of three prior cesarian sections presented at 7 weeks gestation with a possible ectopic pregnancy with implantation into the cesarean scar. She was lost to follow up until she returned at 29 weeks gestation, at which time ultrasound demonstrated placenta percreta with possible extension to the bladder. MRI confirmed placenta previa with full thickness placental invasion of the anterior lower uterine segment. However, bladder wall invasion was not clearly visualized (Figure 2).

Figure 2 Abdominal MRI. There is a markedly heterogeneous placenta with abnormally lobulated morphology. There are numerous T2 hypointense bands of the placenta. The myometrium is not visualized at the anterior lower uterine segment where there is full-thickness placental invasion. There is anterior-inferior bulging of the placenta at this location. Lobules of the placenta demonstrate mass effect on the urinary bladder (arrow); although there is no evidence of full-thickness invasion, it is difficult to exclude due to the mass effect, as well as the bladder being mostly collapsed. There is no evidence of any other adjacent organ invasion. MRI, magnetic resonance imaging.

Our institution’s interdisciplinary placenta percreta team, including members from high-risk obstetrics, anesthesiology, urology, interventional radiology, and the blood bank team, planned cesarean section and hysterectomy at 34 weeks 4 days gestation. However, the patient arrived in the emergency room one week early with painful contractions every two minutes for two hours. She was therefore taken to the operating room. After induction of spinal anesthesia and placement of a central line, cystoscopy was performed, and ureteral catheters were placed. There was no gross placental invasion noted in the bladder.

After a cesarian section was performed and the baby was delivered, the subsequent hysterectomy was complicated by class 4 obstetric hemorrhage, with an estimated blood loss of 40 L, requiring activation of a massive transfusion protocol. The patient received 76 units of packed red blood cells, 36 units of fresh frozen plasma, 18 units of cryoprecipitate and 14 units of platelets. She suffered from multiple periods of severe hypotension during the operation. Diffuse brisk bleeding required removal of adherent placental tissues embedded into adjacent structures including the pelvic side wall and the bladder. Once the uterus was removed, a 10 cm inadvertent cystotomy was noted at the bladder dome, without injury to trigone or ureters. The bladder edges were approximated in two running layers of absorbable suture. The bladder closure was tested with 150 cc of normal saline, which confirmed a water-tight closure. Due to concern for ongoing bleeding, the patient was taken from the operating room directly to the interventional radiology suite, where she underwent bilateral internal iliac (hypogastric) artery embolization with Gelfoam. Right angioembolization was performed proximally on the artery in the right side and distally on the left.

She was transferred to the intensive care unit where she stabilized. She was extubated on post-operative day (POD) #1 and was ultimately discharged home on POD #8 with a foley catheter, acetaminophen 650 mg every 6 hours (q6h) for 10 days, diclofenac gel 1% q8h for 21 days, nitrofurantoin 200 mg q12h for 6 days, oxycodone 5 mg q4h prn for 6 days, tamsulosin 0.4 mg q24h for 3 days, and oxybutynin 15 mg q24h for 3 days. On POD #12, a fluoroscopic cystogram revealed small volume intraperitoneal contrast extravasation at the right dome of the bladder with possible vesicovaginal fistula. The catheter was left in place. On POD #17, the patient presented to the Emergency Room with burning pain at the foley site. A CT cystogram showed a 4 cm by 1 cm defect involving the midline bladder dome, compatible with intraperitoneal bladder leak (Figure 3). The extravasated contrast was seen to communicate with the vaginal cuff. She had no pelvic fluid collections or abscess. Due to her recent major surgery, she was managed conservatively at this time with continued foley catheter drainage as reconstructive surgery was planned. On POD #35, a repeat CT cystogram showed continued large volume extravasation, and post-drainage film showed clearance of contrast through the foley catheter.

Figure 3 CT cystogram. A Foley catheter balloon is within the urinary bladder. There is a 4.5 cm × 1.3 cm defect in the midline of the bladder dome (arrow) with extravasation of a large volume of contrast into the peritoneum surrounding heterogeneous material containing small foci of air, which likely reflects surgical packing material. The contrast appears to be contained within the midline pelvis surrounding the packing material and extending into the right hemipelvis. The extravasated contrast communicates with the vaginal cuff. (A) Sagittal view; (B) coronal view. CT, computerized tomography.

On POD #41, she was brought back to the operating room. An exploratory laparotomy revealed complete dehiscence of the cystotomy repair with a walled-off urinoma in communication with a completely dehisced necrotic vaginal cuff, forming a large vesicovaginal fistula. The vaginal cuff was mobilized away from the bladder, debrided, and closed in a figure-of-eight fashion. A vaginal exam revealed at least 8 cm of vaginal length. The bladder edges appeared necrotic, and so a partial cystectomy was performed to excise the devitalized portion of the bladder. The bladder was closed vertically to avoid overlapping suture lines with the vagina. A running suture was used for the inner mucosal layer followed by interrupted figure-of-eight sutures for the muscularis layer. The bladder closure was tested with 150 cc of normal saline, and there was no leak. A flap of peritoneum from the reflection over the bladder was mobilized and interposed over the suture line. A Jackson-Pratt drain and foley catheter were placed. The patient recovered well and was discharged home 2 days after surgery with acetaminophen 975 mg q6h prn for 30 days, ketorolac 10 mg q6h for 20 days, oxybutynin 15 mg q24h for 30 days.

Two weeks post-operatively, a cystogram revealed no leak and the foley catheter was removed. At one month post-operatively, cystoscopy revealed an intact suture line and capacity of at least 200 cc. At her most recent follow-up, approximately 3 months after the repair, she had no urinary complaints and reported feeling like herself again.

All procedures performed in this study were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent for publication of this case report and accompanying images was not obtained from the patient or the relatives after all possible attempts were made.

Discussion

We present a particularly devastating case of a 30-year-old woman who suffered severe morbidity related to PAS with invasion of the urinary bladder. This case demonstrated massive hemorrhage requiring bilateral hypogastric angioembolization, later complicated by bladder dome and vaginal cuff necrosis, urinoma and vesicovaginal fistula (VVF).

This case report details urological complications of PAS that are rare when experienced in isolation, but their co-occurrence makes them particularly remarkable. As such, the case illuminates several important considerations for patients with PAS, including the relevant medical history diagnostic testing, the importance of an interdisciplinary team approach, and the need for preparation for potentially devastating surgical complications. This report is limited by the lack of information around the patient’s loss to follow-up as well as lack of long-term outcomes on her the quality of life.

The most common urologic injury in PAS surgery is cystotomy. Interestingly, the International Federation of Gynecology and Obstetrics (FIGO) guidelines recommend intentional cystotomy in placenta percreta with invasion of the urinary bladder because it exposes the extent of the placental invasion, defines dissection planes, and determination of whether resection at the posterior bladder wall is needed (2,8-11).

Maximal bladder preservation is important in the surgical management of PAS with bladder invasion. Prior to dissection of the vesicouterine plane, filling the bladder with saline allows better visualization of the border between the bladder and uterus. During the dissection, hemostatic clips and absorbable sutures can be employed to minimize bleeding, which is most often caused by aberrant placental vessels located in the superficial portion of the vesicouterine pouch (8).

In a technique called the “Triple P Procedure”, if there is posterior bladder wall involvement, the invading placental tissue is left in-situ, and confirmation of placental tissue absorption is confirmed at 8 weeks (12). This avoids operative trauma to the bladder and has been associated with a lower rate of postpartum hemorrhage and hysterectomy, although blood loss was similar to standard techniques. A previous study has also suggested utilizing adjuvant methotrexate post-partum when the placental tissue is left in-situ to increase the rate of placental absorption by decreasing trophoblast activity and placental vascularity (13).

Bladder necrosis after PAS and cystotomy repair is particularly rare, with only a few cases ever reported. Surgical dogma around embolization for postpartum hemorrhage asserts that necrosis should not be expected after embolization due to the vast collaterals arising from branches of the IIA and other vessels in the pelvic region (14). In fact, proximal embolization of the IIA may fail to control PAS-associated postpartum hemorrhage because of these numerous collateral vessels (15). Despite this, some postulate that bladder necrosis can occur if the uterine arteries give rise to the inferior vesical arteries (4).

Rates of vaginal cuff necrosis and VVF are exceedingly low. One study found that only 2 out of 66 (3.0%) patients with placenta percreta who underwent hysterectomy developed a VVF (6). Our patient’s fistula resulted from simultaneous cystotomy necrosis and vaginal cuff dehiscence. VVFs have also been noted in patients with significant pelvic blood loss due to regional trauma or vascular injury (2,7,16,17).

The principles of optimal surgical repair for VVF include favorable tissue conditions free from infection and inflammation, complete excision of the fistula tract, a tension-free anastomosis, multi-layered closure that avoids overlapping suture lines and the interposition of vascularized tissue (18). Several techniques exist for managing VVF, including using various flaps and grafts such as omentum, peritoneum, labial fat pad or gracilis muscle. The omental flap is particularly versatile as it can be harvested both abdominally or vaginally and can cover large defects (19). The lack of randomized controlled trials in the literature presents a challenge to understanding whether bladder necrosis is a common complication of IIA embolization in placenta percreta (5,20).

Conclusions

PAS with invasion into the urinary bladder can result in severe urologic complications. To our knowledge, we present the first case of a particularly morbid case of PAS with resulting urologic complications including cystotomy, bladder necrosis and vesicovaginal fistula formation. There are several surgical techniques that can be employed to preserve bladder tissue and function, including filling the bladder prior to vesicouterine dissection, the use of hemostatic clips during dissection, and the “Triple P Procedure”. In the weeks post-operation, providers should hold a high index of suspicion for bladder necrosis and fistula formation, regardless of its low incidence. Future research should investigate approaches that optimize patient-specific vascular anatomy and early detection of necrosis and fistula formation would greatly benefit patients with placenta percreta.
